VERTEQ 1078234.5.1 1069347.3 Matching Transformer, Precision Engineering for Critical Applications

Power Rating:250W

Operating Frequency Range:300MHz to 1GHz

Input Impedance:50 Ohms

Output Impedance:50 Ohms

Operating Temperature Range:-40°C to +85°C

Insulation Resistance:1000MΩ @ 500VDC

Operating Voltage:250V AC

Dimensions:100mm x 70mm x 25mm

Weight:0.3kg

    This VERTEQ matching transformer is engineered for applications where precise impedance matching is critical, offering unmatched reliability and performance in high-frequency circuits.

    Featuring a high-grade ferrite core, it ensures superior magnetic properties, minimizing power loss and enhancing efficiency.

    With an insulation resistance rating of ≥10MΩ at 500VDC, this transformer guarantees robust electrical isolation, safeguarding sensitive components against potential damage.

    Operating within a wide temperature range from -40°C to +85°C, it is designed to withstand harsh environments, ensuring consistent performance across various industrial settings.

    Equipped with a 50W power rating and capable of handling frequencies between 400kHz and 1MHz, this transformer is ideal for demanding applications requiring high precision and stability.

    The ±1% accuracy in impedance matching ensures that it can seamlessly integrate into complex circuit designs, optimizing signal integrity and system performance.
