Frequency Range:0 Hz – 20 MHz
Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Noise, Arbitrary
Resolution:14-bit vertical resolution
Output Amplitude:2 Vpp into 50Ω
Output Impedance:50Ω
Sampling Rate:up to 40 MSa/s
Memory Depth:16 kpts
Interface:USB, LAN, GPIB
The Tektronix AFG1022 Arbitrary Function Generator provides versatile signal generation for demanding industrial environments. Its compact design ensures it can fit easily into any workspace without compromising on performance.
With a wide range of supported waveforms, including sine, square, triangle, ramp, pulse, noise, and arbitrary waveforms, this generator is ideal for a variety of applications such as electronics testing, communications, and educational purposes.
Intuitive navigation keys and programmable function keys make it user-friendly and efficient. Default values are user-settable, offering flexibility and ease of use.
Built with reliability and durability in mind, the AFG1022 adheres to international standards such as RoHS/WEEE compliance, ensuring eco-friendliness and longevity. Its robust construction guarantees consistent performance over time.
This generator is compatible with various networking options including Ethernet (Modbus/TCP), RS-485 (Modbus/RTU, peer to peer, coordinated, PC-Link), and open networks (PROFIBUS-DP, CC-Link, DeviceNet). This makes it easy to integrate into existing systems and expand functionality.
