Output Channels:2 channels
Frequency Range:1 µHz to 50 MHz
Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Arbitrary
Amplitude Range:20 mVpp to 10 Vpp
Resolution:14-bit vertical resolution
Phase Shift:+/- 180 degrees
Sampling Rate:100 MSa/s
Bandwidth:50 MHz (-3 dB)
Interface:USB, LAN, GPIB, RS-232
The Tektronix 5A18N Function Generator is engineered for precision and reliability. With its advanced waveform generation capabilities, it supports a wide range of waveforms including sine, square, triangle, ramp, pulse, noise, and arbitrary waveforms. The frequency range extends from 0.1 µHz to 20 MHz, offering unparalleled flexibility for various applications. The amplitude range of 20 mVpp to 10 Vpp ensures high signal strength and clarity. The device boasts a resolution of 1 µHz / 1 µV, providing exceptional accuracy and consistency. With up to 5th harmonic support, it caters to demanding applications requiring complex signal analysis. The modulation types include AM, FM, PM, FSK, and PWM, making it suitable for advanced communication and testing scenarios. Memory depth of up to 16k points allows extensive waveform storage and manipulation. The interface options include USB, LAN, GPIB, and RS-232, ensuring seamless integration with various systems and networks.
