Operating Voltage:AC/DC 24V
Current Consumption:Max. 10mA
Operating Temperature Range:-25°C to +60°C
Number of Keys:32 Short-Stroke Keypads
LED Indicators:32 Surface Mounted LEDs
Terminal Configuration:16 Digital Input (DI) & 16 Digital Output (DO) Terminals
Communication Interface:PROFIBUS DP12
Material:Rugged Plastic Enclosure
Size:Compact, Easy to Mount
Connection Type:Industry Standard Connector
The SIEMENS 6AV3688-3ED13-0AX0 Push Button Panel is engineered for high performance and reliability in harsh industrial environments. Its robust metal housing ensures durability against wear and tear, making it suitable for continuous operation in challenging conditions.
Featuring 32 short-stroke keys with integrated surface LEDs, this panel offers intuitive user interaction and immediate feedback, enhancing operator efficiency. The keys are specifically designed for quick, precise actuation, crucial for time-sensitive applications.
With support for Profibus DP12 interface, the panel seamlessly integrates with various automation systems, facilitating data exchange and control across multiple devices. This connectivity feature is pivotal for modern factory floors aiming to leverage the benefits of Industry 4.0 technologies.
The inclusion of 32 inputs and outputs provides ample flexibility for complex control scenarios, allowing for the implementation of sophisticated automation logic. Whether managing machinery, monitoring processes, or controlling sequences, the panel’s versatile input/output capabilities ensure comprehensive coverage of industrial needs.
Operating within a wide temperature range from -20°C to +60°C, the panel is designed to withstand extreme environmental conditions without compromising functionality. Its IP65 rating further underscores its suitability for outdoor or dusty indoor installations, ensuring reliable performance under diverse circumstances.
