Product Type:Module
Model ID:TM2AMI2HTN
Schneider Type Designation:Analog Input Module
Input Range:Modicon M238 logic controller
Component Type:Analog Input
Analog Input Number:2
Input Level:High
Input Type:Current 4…20 mA non differential, Voltage 0…10 V non differential
Supply Voltage:External 24 V DC
Supply Voltage Limits:20.4…28.8 V
Electrical Connection:1 removable screw terminal block
Current Consumption:40 mA @ 24 V DC external, 50 mA @ 5 V DC internal
Controller Side Supply:19…30 V DC
Sensor/Controller Side Supply:20.4…26.4 V DC
Supply Current:<= 2 A
Rated Insulation Voltage:2000 V between terminals/mounting rails
Product Weight:0.43 kg
The Schneider TM2AMI2HTN Analog Input Module is an essential component for modern industrial control systems, designed to seamlessly integrate with Schneider‘s Modicon M238 logic controllers. This module excels in providing high-precision analog signal conversion, crucial for real-time monitoring and control applications.
With its robust design and wide input voltage range, the TM2AMI2HTN ensures reliable operation across various industrial settings, from harsh manufacturing environments to sensitive data acquisition tasks.
Featuring a removable screw terminal block for easy installation and maintenance, the module supports both current (4…20 mA) and voltage (0…10 V) inputs, catering to diverse sensor types and application requirements.
Equipped with an external power supply and capable of handling up to 40 mA at 24 V DC externally and 50 mA at 5 V DC internally, the Schneider TM2AMI2HTN guarantees efficient power management and enhanced system performance.
Certified to IEC 61131-2 standards, this module ensures compatibility and safety in accordance with international norms, making it a trusted choice for professionals seeking high-quality, reliable industrial solutions.
