Product Model:140NOE77111
Manufacturer:Schneider Electric
Module Type:Ethernet Network TCP/IP Module
Compatibility:Modicon Quantum PLC Platform
Communication Protocols:Ethernet TCP/IP, Modbus Messaging
Input/Output Scanning:Supported
Global Data:Supported
Faulty Device Replacement (FDR):Supported
Bandwidth Management:Supported
SNMP Agent:Integrated
Diagnostic Web Server:Integrated
Web Pages Customization:Supported
Power Supply:From Rack Power Supply
Current Consumption:750 mA @ 5 V DC
Weight:0.345 kg
Coating:Conformally Coated
The SCHNEIDER 140NOE77111 is a versatile and robust FactoryCast module specifically engineered for use with Modicon Quantum PLC systems. Designed for seamless integration within modern industrial networks, it offers advanced Ethernet connectivity through its support of TCP/IP protocol at speeds up to 10/100BaseTx. Key features include Modbus messaging, which ensures efficient communication between devices, and I/O scanning, which provides real-time monitoring of input/output operations.
The module’s global data handling capability allows for consistent and reliable data exchange across multiple nodes, enhancing overall system performance. Additionally, it includes Faulty Device Replacement (FDR) functionality, which helps to quickly identify and replace malfunctioning devices without interrupting production processes. This feature significantly improves operational continuity and reduces downtime.
Bandwidth management tools allow users to optimize network traffic, ensuring smooth operation even under heavy load conditions. The module is equipped with an SNMP agent and a comprehensive diagnostic web server, offering access to rack viewer, data editor, alarm viewer, graphic editor, and SOAP/WSDL server functionalities via a user-friendly interface. These tools enable remote diagnostics and configuration, facilitating proactive maintenance and troubleshooting.
Conformal coating on the module protects it from harsh environmental conditions, ensuring reliable operation in challenging industrial settings. The inclusion of Web Designer configuration software (not Full Edition) provides users with essential configuration tools, allowing for easy setup and customization of the module’s settings.
