Channels:16
Switch Rating (Continuous):5A
Contact Type:SPST
Relay Form Factor:PXI
Operating Voltage:DC 12 to 48V
Operating Current:Up to 5A per channel
Operating Temperature Range:-20°C to +70°C
Relay Life:Over 100 million cycles
Mounting Style:Panel Mount
Dimensions (WxDxH):170mm x 104mm x 54mm
Weight:Approx. 0.5kg
The PXI-2564 is specifically engineered for integration into advanced test and measurement systems, providing reliable switching capabilities across a wide range of voltages and currents.
Each of the 16 SPST channels supports a maximum current of 5A, ensuring that it can handle a broad spectrum of applications, from low-power electronics testing to high-current motor control.
Featuring a compact 3U PXI form factor, this relay module optimizes space utilization in your test bench setup, making it an ideal choice for both new and existing PXI-based systems.
With its robust design and ability to withstand extreme temperatures ranging from -40°C to +85°C, the PXI-2564 is suitable for deployment in harsh environments without compromising performance.
The PXI-2564 includes a PXI Bus interface for seamless communication with other PXI modules and accessories, facilitating easy integration into complex test and measurement configurations.
