Motor Type:Low-Torque Rotary Actuator Motor
Model Number:M9484F1031
Designation:Modutrol IV
Power Supply Voltage:24 Vac
Operating Frequency:50 Hz, 60 Hz
Power Consumption:15 W
Input Signal Resistance:135 ohms
Dimensions:164 mm H x 140 mm W x 185 mm D
Weight:7.5 lb
Auxiliary Switch Cam Timings:30 seconds (90° stroke), 60 seconds (160° stroke)
Other Timings Available:Customizable upon request
The Honeywell M9484F1031 Modutrol IV motor is engineered for precision control in a variety of industrial settings. Its robust design ensures reliability and longevity even in the most demanding environments.
Featuring a versatile low-torque rotary actuation capability, this motor is ideally suited for applications requiring fine control, such as valve actuation, robotics, and automation systems.
With its non-spring return and integral spring return options, the M9484F1031 allows for flexible positioning and return-to-center functionality, providing operators with the control they need.
Built with a 24 Vac supply, this motor operates efficiently across various industrial frequencies, ensuring compatibility with a wide range of systems and equipment.
The M9484F1031 comes equipped with an auxiliary switch cam for safety monitoring, enhancing operational safety and system integrity. Its weather-resistant NEMA 3 housing protects against environmental elements, making it suitable for outdoor installations or harsh indoor conditions.
With a temperature range of -20°C to +60°C, this motor is designed to withstand varied operational climates, ensuring consistent performance throughout its lifespan.
