Model:SR745-W2-P1-G1-HI-E-H
Manufacturer:GE
Winding Configuration:Per Phase 2
Resistant Temperature Device (RTD):Type 3 wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum
Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA
Maximum Continuous Voltage Output:273 V
Display Type:40 character Enhanced LCD
Dimensions:Height 9″, Width 7″, Depth 7 ⅛”
Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz
Designed for industrial use, the GE SR745-W2-P1-G1-HI-E-H is a robust control system built to handle the demands of transformer management and protection. Its enhanced 40-character display provides clear, easy-to-read information, ensuring operators have real-time insights into system status.
The expanded keypad allows for quicker and more accurate manual entry of setpoints, enhancing operational efficiency. With a compact size of 9 inches high, 7 inches wide, and 7.125 inches deep, this system fits seamlessly into existing industrial setups without requiring extensive modifications.
Safety is a top priority, and the GE SR745-W2-P1-G1-HI-E-H includes a transformer protection system that can be mounted on a standard 19-inch panel. Care must be taken during installation to ensure that the door to the chassis can open and close freely without interference from other components.
Real-time alerts are provided through a number of LEDs located on the front of the case, which notify users of various statuses and errors. This feature helps prevent costly downtime by quickly identifying and addressing issues.
The system supports both DC and AC power sources, with a wide range of voltages and frequencies, making it adaptable to diverse industrial environments. The RTD type and analog output specifications ensure precise temperature monitoring and control, critical for maintaining optimal performance.
