GE SR469 – 469-P5-H1-A20-E Motor Management Relay

Protection Type:Motor Management Relay

Model Number:469-P5-H1-A20-E

Brand:General Electric (GE)

Input Capacity:Multiple RTD inputs

Temperature Determination:Actual temperature and hottest point

Wire Composition:Three-wire system: 100 ohm Nickel, 120 ohm Nickel, 10 ohm Copper, 100 ohm Platinum

Current Monitoring Range:Programmable up to 19,200 baud

Enclosure Rating:20-X

Frequency Compatibility:48-62Hz

Phase CT:5A

Voltage Ratings:90-300VDC, 70-265VAC

Overvoltage Category:II

Insulation Voltage:300V

Pollution Degree:2

Output Channels:4 Analog

RS-232 Interface:9600 baud, programmable up to 19,200 baud

    The GE SR469 469-P5-H1-A20-E Generator Management Relay is a comprehensive solution for monitoring and managing the health and efficiency of industrial motors. It seamlessly integrates into various applications, ensuring the protection of your critical machinery.

    With its advanced multiple RTD inputs, the relay accurately determines both the actual temperature and the hottest point within the motor system, allowing for precise monitoring and proactive maintenance.

    Featuring a durable and user-friendly design, the front panel of this relay includes an RS-232 program port interface with a programmable baud rate, offering flexibility and convenience for integration and setup.

    The draw-out handle is designed with a locking mechanism, ensuring the security of the relay module during operation and maintenance, thus preventing unauthorized removal and enhancing operational safety.

    Engineered to withstand harsh industrial environments, the GE SR469 469-P5-H1-A20-E Generator Management Relay boasts an enclosure rating suitable for various conditions, coupled with high insulation voltage ratings and pollution degree resistance, making it a reliable choice for a wide range of industrial applications.
