Manufacturer:General Electric
Model:DS3800HPCA1F
Board Type:Circuit Board
Compatibility:For GE Turbine Control Systems and Mark IV
Dimensions:9.5 x 6 inches
Connector:Right-angled connector with 9 TP test points
LED Indicators:4 Red LED indicators, 1 Amber LED indicator
Switch Component:Single switch component
Components:Metal film resistors, electrolytic and ceramic capacitors, diodes, and 34 integrated circuits
The DS3800HPCA1F is meticulously engineered to ensure seamless integration with General Electric’s Mark IV industrial control systems. This board is a key component for managing the complex operations of turbines and other industrial machinery.
Featuring a unique design with eight contact points and a labeled edge from A to H and a J, this board offers precise connections and ease of installation. It includes two screw points and two plastic clips for secure mounting.
Each component of the DS3800HPCA1F is clearly labeled with a letter and a number, making it easy to identify and install correctly. Additionally, it comes with the manufacturer’s logo (GE) and production location details for authenticity and traceability.
The board includes several red LEDs, an amber LED, and a switch component, enhancing visibility and control during operation. Furthermore, it contains metal film resistors, electrolytic and ceramic capacitors, diodes, and a variety of integrated circuits.
To ensure reliability and performance, the DS3800HPCA1F is built with high-quality materials and rigorous testing standards. It is designed to withstand the demanding conditions of industrial environments.
