GE 760-P5-G5-S5-HI-A20-R: Advanced Feeder Management Relay for Enhanced Distribution System Protection

In stock

The GE 760-P5-G5-S5-HI-A20-R-T is a high-performance feeder management relay designed for monitoring, managing, and protecting distribution feeder systems. It features an enhanced display with Ethernet connectivity and eight 4-20mA analog outputs.

Model:760-P5-G5-S5-HI-A20-R-T

Brand:GE Grid Solutions

Control Power:Standard

Phase Current Inputs:5 A

Zero Sequence Current Inputs:5 A

Sensitive Earth Fault Relay:Yes

Operating Temperature Range:-40°F to +140°F

Pollution Degree:II

Relay Dimensions:Approx. 18cm W, 16.5cm L, 21.5cm H

Analog Input Conversion Range:0 to 21 mA

Ethernet Connectivity:Yes

Enhanced Faceplate:Yes

Red Breaker Closed LED:Yes

Communications:RS232, RS422, RS485, Ethernet

Breaker Monitoring:Closed Red Breaker LEDs

Waveform Capture Channels:4 currents, 3 voltages, 14 logic input states and 8 output relays

The GE 760-P5-G5-S5-HI-A20-R is a cutting-edge feeder management relay from GE Multilin, designed for precise and reliable operation in industrial environments. Equipped with 5 A phase current inputs and 5 A zero sequence current inputs, this relay offers exceptional accuracy and sensitivity. The enhanced faceplate provides an intuitive interface, while the integrated Ethernet connectivity enables seamless communication with other devices and systems. The eight 4-20mA analog outputs allow for versatile control and monitoring applications. Additionally, the Red Breaker Closed LED indicator ensures immediate status updates and enhances system safety. Designed to operate in harsh conditions, the relay has a wide ambient storage temperature range from -40°F to +176°F and an operating temperature range of -40°F to +140°F. Its compact size of approximately 18cm wide, 16.5cm long, and 21.5cm high makes it ideal for space-constrained installations. The pollution degree II rating guarantees robust performance even in contaminated environments.
