Type:CompactLogix Motion Control Module
Model:1769-HSC
Technology:Ethernet Communication
Operating Temperature:-10°C to +60°C
Storage Temperature:-40°C to +85°C
Power Consumption:2.5W (Max)
Dimensions:105mm x 50mm x 25mm
Communication Protocols:[“EtherNet/IP”,”Modbus TCP/IP”]
Counter Channels:2
Encoder Compatibility:Up to 1 MHz
Connector Type:M12 Connector
Number of Inputs/Outputs:20/20
The 1769-HSC CompactLogix Counter/Encoder is engineered for applications requiring precise motion control, such as robotics, packaging machines, and CNC systems. Its high-resolution encoder ensures accurate position feedback, enabling precise control and minimizing errors in motion paths.
Featuring an open collector output, this encoder is versatile and can be easily integrated into various control systems. It supports multiple communication protocols, including ControlNet, DeviceNet, and EtherNet/IP, facilitating seamless communication with other devices in the network.
Crafted from durable materials, the 1769-HSC is built to withstand harsh industrial environments, ensuring long-term reliability and maintenance-free operation. Its compact design allows for easy installation and integration into existing systems without compromising on performance.
With a maximum counting rate of up to 10 MHz, the 1769-HSC is capable of handling high-speed applications without sacrificing precision. This makes it an ideal choice for industries where speed and accuracy are paramount, such as automotive, pharmaceutical, and food processing.
To further enhance its utility, the encoder comes with customizable settings through the Rockwell Automation Studio software, allowing users to tailor its functionality to their specific application needs. This level of flexibility ensures that the 1769-HSC meets the diverse requirements of modern industrial automation.
