Brand:EMERSON
Model:A6500-RC
Channels:16
Relay Type:Output Relay
Rating Current:10A
Voltage Rating:AC 240V / DC 30V
Contact Rating:500V AC / 100V DC
Contact Capacity:10A @ 250V AC / 5A @ 30V DC
Operating Life:10,000,000 cycles
Insulation Resistance:≥1000MΩ @ 500V DC
Temperature Range:-20°C to +70°C
Enclosure Type:IP20
Operating Voltage Frequency:50/60Hz
Dimensions:W: 95mm x L: 100mm x H: 35mm
Weight:0.15kg
Material:Aluminum
The EMERSON A6500-RC module boasts a robust and compact design, making it an ideal choice for space-constrained industrial environments. It supports a wide range of voltages and currents, ensuring compatibility with diverse system requirements.
Each channel is equipped with a high-reliability relay, delivering consistent performance even under harsh conditions. This makes it particularly suitable for applications requiring precise control over actuators, motors, and other electrical devices.
With a temperature rating from -20°C to +70°C, this module can operate reliably in extreme environments, from cold storage facilities to hot manufacturing floors. Its wide operating voltage range from 12V to 48V DC ensures flexibility in power supply options.
The EMERSON A6500-RC is designed with ease-of-use in mind, featuring simple installation procedures and intuitive operation manuals. Its modular construction allows for easy maintenance and scalability in larger systems.
Certified by UL, CE, and CSA, the EMERSON A6500-RC complies with stringent international safety standards. This ensures not only high operational safety but also broad global acceptance, facilitating its use across different geographical markets.
