Model Type:Redundant Dual Channel Communication Module
Manufacturer:Allen-Bradley
Model Number:1756-CN2R/C
Channels:2
Current Rating:Drawn: 970 MA at 5.1 VDC, 1.7 MA at 24 VDC
Isolation:30 V (Continuous)
Enclosure Type:Open Type
RFI Suppression:Radiated: 10 V/M with 1 KHz sine-wave 80% AM from 80 – 2000 MHz, 10 V/M with 200 Hz 50% pulse 100% AM at 900 MHz
Temperature Rating:0 – 60 DEG C
Power Dissipation:Not specified
Connection Compatibility:ControlNet A/B to backplane, and ControlNet A to ControlNet B, no isolation between NAP or USB and backplane
Type Tested:500 VAC for 60 SEC
Communication Speed:Not specified
Communication Protocol:ControlNet
This ControlLogix Communication Module by Allen Bradley is designed to provide robust and reliable connectivity in demanding industrial environments. Its dual-channel redundancy ensures that critical operations continue without interruption, even in the event of a single channel failure.
Equipped with advanced communication protocols, this module facilitates seamless integration with other ControlLogix systems, enhancing overall system efficiency and performance. The high-speed Ethernet/IP bridge supports fast data exchange, making it ideal for applications requiring real-time data processing.
With its open type enclosure, the module is easy to integrate into various industrial settings. The RFI suppression feature minimizes interference, ensuring stable operation even in noisy environments.
The Allen Bradley 1756-CN2R/C Communication Module is certified for operation within a wide temperature range, from 0 to 60 degrees Celsius, and can withstand harsh environmental conditions, making it suitable for a wide variety of industrial applications.
Designed with user-friendliness in mind, this module is straightforward to install and configure. Its compatibility with Allen-Bradley’s comprehensive line of industrial automation components ensures a seamless setup process.
