Allen Bradley AB 1746-OB32E SLC 500 Digital DC Output Module

Model Type:SLC 500

Model Number:1746-OB32E

Manufacturer:Allen Bradley

Output Channels:32

Output Voltage Range:5 – 50 VDC

On-State Voltage Drop:1.2 V

Off-State Output Leakage:1 MA

Load Capacity:1 MA

Current Rating:{“Backplane”:”190 MA”,”Continuous Current Per Output”:”0.25 A at 60°C”,”Continuous Current Per Module”:”8 A at 60°C”}

Isolation:{“Communication Circuits”:”500 VDC”,”Backplane”:”1500 VAC”}

Processor:SLC 500

Enclosure Type:Open Type

Mounting Method:Chassis

Temperature Rating:0 – 60°C

Environmental Conditions:5 – 95% non-condensing relative humidity

    The Allen Bradley AB 1746-OB32E module boasts exceptional reliability and performance, making it a preferred choice for complex industrial automation projects. Its robust design ensures stable operation under a wide range of environmental conditions, enhancing system uptime.

    Each channel is equipped with a precise on-state voltage drop, ensuring minimal power loss and optimal control accuracy. The off-state leakage current is kept to a minimum, minimizing the risk of unintended activation.

    Featuring advanced isolation technology, this module guarantees protection against electrical interference, ensuring reliable data transmission and preventing potential hazards in industrial settings.

    The open-type enclosure allows for easy integration into existing systems, and its compact size makes it suitable for space-constrained environments. It is compatible with a variety of mounting options, including chassis mounting, for flexible installation.

    With a temperature rating of 0 to 60 °C and non-condensing relative humidity, this module is designed to withstand harsh industrial conditions, ensuring continuous operation without overheating or moisture-related failures.
