Nominal Input Voltage (AC):230 to 480 V
Input Frequency (AC):47 to 63 Hz
Nominal Input Current (AC):14 A (continuous)
Continuous Output Current:15 A
Intermittent Output Current:30 A
Output Power:1.5 kW @ 230VAC, 3.0 kW @ 460VAC
Shunt On Voltage:420V DC
Control Specifications:Commutation, SVM, Digital PI/VID, Digital PID
The Allen-Bradley 2098-DSD-HV150X-DN Servo Drive is engineered for unmatched precision and reliability in demanding industrial environments. Its advanced control algorithms ensure seamless integration with Allen-Bradley’s Logix 5000 series controllers and interface modules, optimizing performance across multiple axes.
With its versatile 3-phase AC input and robust output capabilities, this servo drive delivers exceptional torque and speed, making it suitable for applications requiring high accuracy and fast response times. The integrated indexing functionality enhances its utility in complex manufacturing processes.
Featuring an ultra-low shunt resistance of 40 ohms, this drive ensures minimal power loss and maintains peak performance under varying loads. Its compact design, measuring just 22.96 pounds, facilitates easy installation and integration into existing systems without compromising on power or functionality.
The drive’s modular architecture allows for straightforward expansion and customization, catering to evolving production needs. It supports multi-turn absolute encoders, enabling real-time monitoring and control of position, velocity, and acceleration.
Designed with safety and ease of use in mind, the Allen-Bradley 2098-DSD-HV150X-DN Servo Drive comes equipped with comprehensive diagnostic tools and self-monitoring features. This ensures continuous operation and quick troubleshooting, reducing downtime and maintenance costs.
