Nominal Input Voltage (AC):100-240VAC, RMS
Nominal Input Frequency (AC):47-63Hz
Output Voltage (AC):100-240VAC
Output Power (Continuous):1kW
Output Current (Continuous):1A
Output Current (Intermittent):30A
Bus Capacitance:1880 µF
Bus Overvoltage:400 Vdc
Energy Absorption Capability:125 Joules @ 115VAC, 51 Joules @ 230VAC
Introducing the Allen-Bradley 2098-DSD-020X Digital Servo Drive, the pinnacle of precision and efficiency in industrial automation. Designed for seamless integration with Allen-Bradley’s Kinetix Servo Motor series, this ultra-durable drive ensures smooth motion control and precise positioning, making it an indispensable tool in any manufacturing line.
Featuring a compact size of 2.1kg (4.6lbs) and dimensions of 98.1mm x 32.77mm x 65.02mm, the 2098-DSD-020X offers unparalleled versatility, fitting seamlessly into a wide range of equipment configurations without compromising on performance.
Equipped with a robust design that supports a nominal input current of 18 A, rms, and 100 Ampere for series A and B, 20 Ampere for series C at 230VAC (0-pk), this drive ensures reliable operation across various industrial environments.
The 2098-DSD-020X boasts an impressive energy absorption capability of 125 Joules when operated at 115VAC and 51 Joules at 230VAC input, safeguarding against sudden voltage surges and ensuring system integrity under challenging conditions.
With its built-in indexing capability, the drive simplifies complex motion sequences, allowing users to store and select pre-configured servo motor movements from the drive’s memory, enhancing productivity and reducing setup times for repetitive tasks.
