Dimensions:632.5 mm (24.9 in) L x 25.4 mm (1 in) D
Module Capacity:1 IAM, 7 Additional
Weight:9.7 lbs (4.43 kg)
Applicable Drive Systems:230 or 460 Volt
Compatible Modules:Up to 8 Axes
Torque Limit:Up to 5.08 N•m (45.0 lb•in)
The Allen-Bradley 2094-PRS8 Power Rail is a robust 8-axis inverter system engineered for demanding industrial environments. Its compact yet powerful design ensures compatibility with both 230V and 460V drive systems, providing unmatched flexibility for various applications.
Featuring a modular structure, the 2094-PRS8 supports one Integrated Analog Module (IAM) and up to seven additional modules, catering to diverse operational needs. This rail system is part of the renowned Allen-Bradley 2094-PRS-x Series, ensuring durability and performance.
Weighing 9.7 lbs (4.43 kg), the 2094-PRS8 is lightweight yet sturdy, making it easy to install and maintain. Its compatibility with the Kinetic 6000 drive systems simplifies integration, enhancing efficiency and reducing setup time.
The 2094-PRS8 measures 63.25 cm (L) x 55.12 cm (W) x 26.67 cm (H), fitting seamlessly into existing infrastructure without compromising space. This dimensionally optimized design allows for efficient use of floor space in industrial setups.
For safe and reliable installation, always follow the provided guidelines. Ensure the mounting hardware, including M6 Metric (1/4×20) bolts, is tightened with up to 5.08 N•m (45.0 lb•in) torque. Connect the braided strap to the ground grid or Power distribution ground for continuous protection against electrical hazards.
