Number of Inputs:4 channels
Supply Voltage Range:20 to 32V dc
Input Current:10mA max per channel
Resistance Range:1 kΩ to open circuit
Accuracy:+/- 0.2% FS
Operating Temperature:-20°C to +70°C
Enclosure Rating:IP20
Dimensions:118 x 70 x 87 mm (4.65 x 2.76 x 3.43 in.)
Weight:630 g (1.39 lb)
The Allen-Bradley 1769-IF4I Analog Input Module is a robust solution for data acquisition in various industrial environments. It boasts 4 dedicated analog inputs, each capable of handling signals from sensors, transducers, or other measurement devices, ensuring accurate data capture for process control applications.
Featuring a compact size and lightweight design, the module is easy to integrate into existing systems without compromising on functionality. Its Ethernet compatibility enables seamless connectivity to a broader network, enhancing system scalability and flexibility.
With a wide supply voltage range of 20 to 32V dc, the 1769-IF4I is designed to operate reliably across different industrial settings, ensuring continuous performance even under varying conditions. This makes it an ideal choice for food processing, petrochemical, pulp and paper, automobile manufacturing, water and wastewater treatment, oil and gas exploration, power generation, and electric utility sectors.
Recognized as an Input/Output module, it has direct access to processor memory, allowing for efficient data transfer between the module and the control system. This feature simplifies programming and maintenance tasks, streamlining the overall operation and management of complex industrial processes.
Leveraging Ladder Logic for data transfer, the Allen-Bradley 1769-IF4I ensures reliable communication protocols, offering users a powerful tool for monitoring and controlling industrial machinery. Its compatibility with all CompactLogix and MicroLogix 1500 LRP Controllers except specific models (1769-QBFC1B, 1769-L16x, 1769-L18x) further enhances its adaptability, making it a valuable asset for modern industrial automation.
