Allen-Bradley 1756-CN2R/C ControlLogix ControlNet Redundant Bridge Module

Model Type:Redundant Bridge Module

Manufacturer:Allen-Bradley

Model Number:1756-CN2R/C

Number Of Channels:2

Current Rating:Drawn: 970 mA at 5.1 VDC, 1.7 mA at 24 VDC

Isolation:30 V (Continuous), Basic Insulation Type

Communication Interface:ControlNet A/B to Backplane, ControlNet A to ControlNet B

Enclosure Type:Open Type

Rfi Suppression:Radiated: 10 V/M with 1 KHZ Sine-Wave 80% AM from 80 – 2000 MHz, 10 V/M with 200 Hz 50% Pulse 100% AM at 900 MHz, 10 V/M with 200 Hz 50% Pulse 100% AM at 1890 MHz, 3 V/M with 1 KHZ Sine-Wave 80% AM from 2000 – 2700 MHz

Temperature Range:0 – 60 °C

Power Dissipation:5.1 W

Environmental Conditions:5 – 95% non-condensing relative humidity

Vibration:2 G

Shock:30 G

Connection:Ethernet

USB Port:Not Included

    The Allen-Bradley 1756-CN2R/C ControlLogix ControlNet Redundant Bridge Module is designed to provide enhanced reliability and redundancy in your industrial automation system by seamlessly connecting two ControlLogix controllers. This robust module ensures that critical operations continue uninterrupted, even in challenging environments.

    Featuring an open type enclosure, this bridge module is easy to integrate into existing systems without compromising on its performance. Its high capacity IP module technology supports a wide range of communication protocols, making it compatible with various industrial applications.

    With its dual-channel design, the 1756-CN2R/C can handle multiple data streams simultaneously, significantly improving the efficiency and responsiveness of your automation network. The integrated redundancy feature further enhances system reliability, offering failover capabilities in case of component failures.

    This module is engineered with advanced RFI suppression technologies, ensuring minimal interference with other electronic devices and maintaining stable communication signals within the frequency ranges from 80 MHz to 2700 MHz. It’s meticulously tested under extreme environmental conditions, including temperature fluctuations and vibrations, ensuring longevity and durability.

    The Allen-Bradley 1756-CN2R/C ControlLogix ControlNet Redundant Bridge Module is a strategic investment for manufacturers looking to enhance their operational efficiency, reduce downtime, and maintain optimal performance in their automation systems.
