Allen Bradley 1746-NO4I SLC 500 Output Module – Industrial Control Solutions

Model Type:Output Module

Model Number:1746-NO4I

Manufacturer:Allen Bradley

Number of Outputs:4

Output Configuration:Digital

Output Voltage Range:5-50 VDC

On-State Voltage Drop:1.2 V

Off-State Leakage Current:1 mA

Load Current per Output:0.25 A

Continuous Current per Module:8 A

Isolation:500 VAC for 1 sec

Temperature Rating:0-60°C

Environmental Conditions:5-95% RH

Power Rating:Backplane: 2.425 W

Enclosure Type:Open Type

Mounting Method:Chassis

Input Range:-10 to +10 VDC

Current Input Rating:Plus/Minus 30 mA

    Engineered for seamless integration into Allen Bradley’s SLC 500 series, the 1746-NO4I Output Module is a high-performance component designed for industrial automation applications requiring precise digital control.

    Each of the four output channels provides robust and stable performance, ensuring consistent and accurate operation in diverse industrial environments.

    With its compact size and modular design, the 1746-NO4I is easily adaptable to various control configurations, facilitating efficient system expansion and modification.

    The module supports a wide range of voltage levels, making it suitable for a broad spectrum of industrial machinery and processes. Its ability to handle different load capacities ensures compatibility with various types of equipment.

    Featuring enhanced isolation and overvoltage protection, the 1746-NO4I ensures reliable operation even under challenging environmental conditions. This feature is critical in preventing unexpected system failures due to electrical interference or power fluctuations.
