Manufacturer:ABB
Model Number:GJR2390200R1210
Relay Type:83SR04E-E
Module Category:Relay Module
Operating Temperature Range:-25°C to +85°C
Rating Current:Up to 10A
Contact Rating:250VAC/30VDC, 10A@250VAC, 40A@30VDC
Insulation Resistance:≥1000MΩ
Protection Class:IP20
Operating Voltage:115VAC, 230VAC, 24VDC
Relay Contacts:SPDT (Single Pole Double Throw)
Operating Frequency:Up to 10kHz
Load Switching Capability:1000VAC, 2A
Switching Delay Time:≤1ms
Lifetime:Over 1 million switching operations
The ABB GJR2390200R1210 83SR04E-E Relay Module is a high-performance solution tailored for industrial control applications. It offers robust functionality with a wide operating temperature range, ensuring reliable operation in harsh environments.
Featuring four independent relay channels, this module provides versatile control over various electrical circuits. Its ability to handle up to 10 amperes at 250 volts AC or 2 amperes at 1000 volts DC makes it suitable for a wide array of industrial needs.
With an input voltage range of 85 to 264 volts AC, the module is designed to operate efficiently in a broad spectrum of power supplies commonly found in industrial settings. The high current rating of 10 amperes ensures it can manage significant loads without compromising performance.
The 83SR04E-E module comes equipped with four relays that are rated for DC 24 volts at 10 amperes, providing precise control capabilities for applications requiring low-voltage switching. This feature is particularly advantageous in systems where precise control and reliability are paramount.
The IP20 protection class ensures that the module is adequately protected against accidental contact and dust ingress, enhancing its longevity and safety in industrial environments. The compact dimensions of 45 x 70 x 27 millimeters and a lightweight of 0.05 kilograms make it easy to integrate into existing control panels, optimizing space usage and facilitating installation.
