ABB Bailey IMAOM01: High Precision Analog Output Module

Module Type:Analog Output

Model Number:IMAOM01

Operating Voltage:24V DC

Output Current:0 to 20 mA

Signal Type:4-20 mA or 0-10 V

Accuracy:±0.02% + 2LSB

Load Capacity:250 Ohm max.

Communication Interface:Modbus RTU

Mounting:Panel Mount

Temperature Range:-25°C to +70°C

Enclosure Rating:IP20

Power Consumption:Typically < 0.2 W

Dimensions:LxWxH: 115mm x 100mm x 46mm

Weight:Approx. 120g

    Introducing the ABB Bailey IMAOM01, a cutting-edge analog output module designed for precision and efficiency in industrial automation environments. This module is built with high-quality materials to withstand rigorous industrial conditions, ensuring long-lasting reliability.

    Featuring a single-channel design, it provides accurate and stable output signals for controlling actuators, motors, and other devices requiring precise voltage or current control. The response time of ≤1ms ensures minimal delay, enhancing operational efficiency.

    The IMAOM01 is compatible with a wide range of industrial protocols, including MODBUS RTU, facilitating seamless integration with various automation systems. Its robust communication capabilities ensure reliable data exchange even in challenging environments.

    With an operating temperature range of -25°C to +60°C and a storage range of -40°C to +70°C, this module is designed to operate reliably across diverse industrial settings. It can withstand extreme environmental conditions without compromising performance.

    In terms of safety and reliability, the ABB Bailey IMAOM01 meets the IP20 protection rating, providing adequate protection against dust and splashes. It also operates within a humidity range of 5% to 95% non-condensing, ensuring stable performance under varying climatic conditions.
