Operating Voltage (V)::860
Reverse Recovery Time (ns)::397
Max Current (A)::0001
Temperature Range (°C)::-55 to +175
Package Type::DPAK
Reverse Voltage (V)::800
Diode Type::Fast Recovery
Insulation Resistance (MΩ)::1000
Maximum Junction Temperature (°C)::+175
This fast recovery diode from ABB is specifically engineered for use in industrial automation where rapid switching and minimal power dissipation are critical. It features a low forward voltage drop and an exceptionally fast reverse recovery time, which ensures efficient operation under various environmental conditions.
The device supports a wide range of operating voltages, making it suitable for diverse industrial applications. With a peak inverse voltage rating of 860V, it can withstand harsh conditions without compromising on performance.
Equipped with Surface Mount Technology (SMT), the 5SDF0860H0003 3BHL000397P0001 offers a compact footprint, enabling easy integration into modern circuit boards. Its robust design and surface mountable package facilitate high-density assembly and space-saving solutions.
Featuring a temperature range from -40°C to +175°C, this diode is suitable for use in extreme environments. This wide operating temperature ensures reliability across different industrial settings, including harsh outdoor conditions or high-temperature manufacturing processes.
With a current handling capacity of 1.5A and a switching frequency of up to 20kHz, this diode provides superior performance in high-speed switching scenarios, reducing power loss and enhancing system efficiency. Its design ensures minimal power dissipation even under heavy loads, contributing to energy-efficient operations.
