Material:High-strength aluminum alloy
Operating Temperature Range:-40°C to +85°C
Insulation Resistance:≥10^9 Ω
Current Capacity:Up to 100A
Connection Type:Mated pin and socket
Connector Dimensions:Length: 200mm, Width: 30mm, Height: 25mm
Operating Life:Minimum 10,000 mating cycles
Engineered for durability and reliability, the ABB 3HAC020643-001 harness bridge connector seamlessly integrates into robotic systems, ensuring stable electrical performance under harsh industrial conditions.
Featuring a high-grade copper alloy material, this connector guarantees excellent conductivity and long-lasting electrical integrity, even in extreme temperatures ranging from -40°C to +85°C.
With a contact resistance of ≤ 5 mΩ and an insulation resistance of ≥ 100 MΩ, the connector ensures minimal power loss and enhanced signal clarity, crucial for precise robotic operations.
Rated for up to 400V AC and capable of handling a current of 25A at this voltage, it is designed to withstand the high power demands of modern robotic contactors.
The connector utilizes M12 x 1.6 pitch screw terminals for secure and easy connection, facilitating quick assembly and disassembly without compromising on the strength of the electrical contact. Additionally, its IP67 protection class makes it suitable for use in environments with dust and water exposure.
