Operating Voltage:24V DC
Data Transmission Protocol:RS-485
Max Data Rate:10 Mbps
Number of Channels:16
Signal Range:-20V to +20V
Temperature Range:-20°C to +70°C
Humidity Range:5% to 95% RH non-condensing
Dimensions:145mm x 110mm x 70mm
Weight:0.5kg
The ABB 3HAB3700-1 Serial Measurement Board is a critical addition to any industrial automation setup, offering unparalleled precision in serial data acquisition. It is specifically engineered to handle demanding industrial environments, ensuring reliable operation under extreme conditions.
This board boasts an expansive measurement range from 0 to 10 VDC, with exceptional resolution and accuracy, making it ideal for applications requiring high-level control and monitoring. Its robust communication interface supports seamless integration with various industrial control systems through RS-485, enhancing system interoperability.
Equipped with a 24 VDC power supply, this measurement board is designed for efficient energy consumption and long-term reliability. It operates within a wide temperature range, from -20°C to +70°C during operation and from -40°C to +85°C when stored, ensuring durability in varied industrial settings.
In terms of design, the ABB 3HAB3700-1 is optimized for ease of installation with a panel-mount design, minimizing space requirements and simplifying integration into existing systems. Moreover, its compatibility with MODBUS RTU protocols facilitates straightforward communication and data exchange with a wide array of automation equipment.
This board is a testament to ABB’s commitment to innovation and quality, providing engineers and manufacturers with a reliable tool for enhancing operational efficiency and productivity in their respective industries.
