Model Type:Redundancy Module
Model Number:1756-RM/A
Manufacturer:Allen-Bradley
Channels:2
Current Rating (5.1 VDC):1.16 A
Current Rating (24 VDC):3.4 MA
Enclosure:Open Type
RFI Suppression:Radiated: 10 V/M, Sine-Wave 80% AM, 80 – 2000 MHz; 10 V/M, 200 Hz 50% Pulse, 100% AM, 900 MHz; 3 V/M, 1 KHZ Sine-Wave, 80% AM, 2000 – 2700 MHz
Display:4 Character Alpha/Numeric
Mounting:Chassis
Temperature Rating:32 – 140 DEG F
Power Supply:Drawn: 1.16 A at 5.1 VDC, 3.4 MA at 24 VDC
Environmental Conditions:Suitable for industrial environments with controlled humidity and vibration
Compliance:IEC 61131-3, IEC 61131-3, EN 61131-3, ANSI/ISA-84.01.01-1996
This module is specifically engineered for ControlLogix systems, ensuring seamless integration and enhanced performance through its redundant architecture. It supports dual power supplies, allowing for fail-safe operation without interrupting the process.
With its robust design, the AB 1756-RM/A is capable of handling extreme temperatures, making it suitable for industrial environments where temperature fluctuations are common. Its open type enclosure facilitates easy installation and maintenance.
Equipped with advanced RFI suppression technology, this module ensures reliable communication in harsh electromagnetic environments. It utilizes state-of-the-art Ethernet/IP Bridge technology for high-speed data transfer, optimizing the performance of ControlLogix-based systems.
The inclusion of a 4-character alpha-numeric display provides quick access to system status information, enhancing operational oversight. The chassis mounting option ensures secure attachment within the industrial automation setup, maximizing uptime and reducing downtime risks.
In summary, the Allen-Bradley AB 1756-RM/A ControlLogix Redundancy Module is a sophisticated solution for enhancing the reliability and safety of industrial control systems. Its comprehensive feature set, combined with its robust build quality, makes it an indispensable component for mission-critical applications.
