Brand:A-B
Model:1746-IV16
Module Type:Digital DC Input Module
Number of Channels:16
Input Voltage Range:10 – 30 VDC
Off-State Input Voltage:3 VDC
Nominal Current:8 mA at 24 VDC
Off-State Current:1 mA
Isolation:Communication Circuits: 500 VDC, Backplane: 1500 VAC
Processor Compatibility:SLC 500
Enclosure:Open Type
Mounting:Chassis
Temperature Rating:0 – 60 °C
Humidity Range:5 – 95% Non-Condensing Relative Humidity
Shock Resistance:30 G
The Allen-Bradley 1746-IV16 DC Input Module is an essential component for any industrial automation setup. With its robust design and reliable performance, this module offers precise digital input capabilities across 16 channels. This makes it perfect for a wide range of applications, including process control, manufacturing systems, and other industrial environments.
Designed with precision engineering, the 1746-IV16 module supports a wide input voltage range of 10 – 30 VDC, ensuring compatibility with various power sources commonly found in industrial settings. Its off-state input voltage of 3 VDC ensures low power consumption and enhanced efficiency.
This module incorporates high-quality components to achieve a nominal current of 8 mA at 24 VDC, making it suitable for demanding industrial environments. Additionally, the off-state current of just 1 mA further enhances energy efficiency and reliability.
Safety is paramount in industrial settings, and the 1746-IV16 module is built to withstand harsh conditions. It features isolation voltages of up to 500 VDC for communication circuits and 1500 VAC for backplane connections, ensuring secure and stable operation. The temperature rating of 0 – 60 °C and environmental conditions of 5 – 95% non-condensing relative humidity make it adaptable to a variety of climates and environments.
Ease of installation and maintenance are key features of the 1746-IV16 module. Designed with open-type enclosures and chassis mounting options, this module can be easily integrated into existing systems. The compact design allows for efficient space utilization, making it a versatile choice for any industrial control application.
